DigitalPanel Lever Lock Series

Main Features Materia：Front Door Trim Zinc Alloy, Back Door Trim Premium ABS Password Capacity：Total Capacity: 200, Max capacity of 100 fingerprints (sharing For Both fingerprint, Password And Card) Mechanical Key：Supply With 2 Keys, Brass Material Working Voltage：4.8V-6.4V Low Voltage Alarm：4.6V-4.8V Working Temperature：-25℃-70℃ Working Humidity：20%-95% RH (Relative Humidity) Daily Power Supply：4pcs "AA" Alkaline Battery Back-up Power Supply：5V, Type-C Port Locking Mechanism：With A Bolt, Backset 60-70mm Adjustable Fitting Door Thickness：Standard 35-50mm. Other Requirements Can Be Customized Application Range：Entrance Doors Of Condo, Residence, Office Building, Hospital, School And Etc

Main Features Main Material：Aviation aluminum, CNC precision carving technology Capacity for face, fingerprint, password and IC card：120 users in total Fingerprint Capacity：50 pieces Mechanical Key：Supply With 2 Keys, Brass Material False Rejection Rate：≤0.1% Operating Voltage：6.4V-8.4V Operating Temperature：-25°C-65°C Operating Humidity：20%-93% RH (Relative Humidity) Operating Power Supply：4200mAh + 2500mAh lithium batteries Backup Power Supply：5V, Type-C port Stand-by Current：<80μA Dynamic Current：<380μA Installation Door Thickness：40-120mm Application Range：Entrance doors of apartments, residences, office buildings, hospitals, schools, etc.

Main Features Materia：Aluminium Alloy Password Capacity：Total Capacity: 250, Max capacity of 100 fingerprints (sharing For Both fingerprint, Password And Card) Mechanical Key：Supply With 2 Keys, Brass Material Responding Speed：≤0.05S Working Voltage：4.5V-6.5V Low Voltage Alarm：4.6V-4.8V Working Temperature：-20℃-66℃ Working Humidity：5%-95% RH (Relative Humidity) Daily Power Supply：4pcs "AA" Alkaline Battery Back-up Power Supply：5V, Type-C Port Locking Mechanism：Backset 60-70mm Adjustable Fitting Door Thickness：Standard 35-50mm. Other Requirements Can Be Customized Application Range：Entrance Doors Of Condo, Residence, Office Building, Hospital, School And Etc

Main Features Materia：Aluminum Alloy Verification To Unlock：Both Front Side And Back Side Available Capacity：10 Masters(Sharing For Fingerprint, Password And Card) 512 Normal Users (Sharing For Fingerprint, Password And Card. Maximum 100 For Fingerprint; Maximum 512 For Password And Card) Mechanical Key：Supply With 2 Keys, Brass Material Responding Speed：≤0.05S Working Voltage：7.4V Low Voltage Alarm：6.8V Working Temperature：-25℃-70℃ Working Humidity：20%-85% RH (Relative Humidity) Daily Power Supply：Lithium Battery (Usable Around 3600 Times Of Unlocking After Fully Charged) Fitting Door Thickness：Standard 50-110mm. Other Requirements Can Be Customized Application Range：All Kinds Of Metal Entrance Doors And Gates
